Netwave NW6000 Retrofit Kits

The Netwave VDR Upgrade Kit offers significant economic, innovation and installation benefits for ship owners, managers and service teams upgrading or replacing older VDR systems. With technological and software tools to reduce installation times, designed to minimise vessel disruption by using existing system footprint, combined with cost saving warranty on re-usable components, the NW6000 Upgrade kit accelerates and simplifies VDR retrofits.

Designed and manufactured by Netwave, the NW series is the natural technology upgrade path for NW4000 and Rutter VDRs, ensuring component compatibility and improved service consistency. The specifically designed VDR installation kit reduces fitting complexity, utilising new mechanical and software tools to help service engineers reduce time onboard to as little as a day and a half. The cost-effective system can incorporate the re-warranty and deployment of existing components, to reduce the overall refit cost.

Features

Innovative automatic sensor configuration and the ability to copy existing Rutter or NW4000 configurations to the new system saves considerable engineering time
New touch screen playback software quickly allow crew access to key sensor information, with comprehensive radar & ECDIS screen and an operational performance test (OPT), quickly confirms all channels are recording as configured.
Installation plate allows service engineer to utilise existing system footprint and removes the need to have welding onboard during the fitting, the design has multiple capsule configurations, including the L3 capsule offering complete flexibility.
Stable VDR components and cabling can be reused, reducing the direct cost and fitting disruption. Uniquely, reused components have warranty extended from the date of new retrofit without additional cost.
Pre installation survey avoids vessel disruption by identity access and component needs before engineers start the installation.

Discover more in the TECHNOLOGY tab below

SPECIFICATIONS TECHNOLOGY

Bridge Control unit (BCU)	Touch Screen
Core module inside 19” rack	New VDR is installed in the existing space
Digital Acquisition	Gateway between the Core Module and a wide range of interconnecting sensors
VHF Interface	Dual function VHF interface and microphone power source
Mics	Plug and play replacement option utilizing existing cabling
Screen Frame Grabber	Increased number of channels including connecting VGA and PoE
Player V2	Easy install allows both playback and offers touch screen interface for ease of use

Technology Overview

VDR Retrofit

As a SOLAS mandated technology your Vessel Data Recorders’ (VDR) dependability is integral to the effective management of your fleet. Reliability, usability and minimized downtime are the foundation blocks for a trouble free VDR. By upgrading your aging system to a Netwave NW6000 you can ensure ease of installation with minimal downtime, while providing crew friendly features and access to a global service network.

Seas of Solutions’ range of Netwave Upgrade Kits accelerate the upgrade of a wide range of VDR models. By simplifying installation times and upgrading to a Netwave VDR, vessel owners reduce the immediate installation cost and vessel downtime, diminish the risk of supporting aging hardware obsolescence and enhance both the future reliability and capabilities of their VDR solution.

Upgrade to Save Time and Money

Upgrade specialists help reduce VDR upgrade costs with pre-installation survey forms to avoid unplanned disruption, while advanced upgrade kits reduce installation time by an average of one day. There is also the option to re-utilize existing sensor modules and cabling (where feasible) to further accelerate installation.
Improve your VDR reliability and reduce servicing downtime by removing dated equipment reliant on sometimes scarce components, which could extend service times and hold ships at port.
Gain access to one of the largest global service networks, with over 1300 certified engineers.
By upgrading older VDRs near their end service, vessels can reduce the lifetime cost of ownership by lowering maintenance and annual APT costs and gain the peace of mind of ten-year service guarantee and seven years parts support after final manufacture date*.
Fully compliant with July 2014 IMO installation standard MSC 333.(90), Netwave NW6000 VDRs offer technological confidence in a solution which has a global install base of more than 6,000 vessels.

*10/7 warranty applies to new components only

Benefits of Netwave NW6000 VDR Upgrade Kits

As the natural upgrade route, the Netwave NW6000 Upgrade Kits provide economic and functional benefits for the conversion of existing G1 19” rack and the G2 & G3 series VDRs.

Ease of replacing the Fixed Capsule:	NW6000 VDR standard components includes a welding plate with pre-molded holes to replace any capsule (L3; Fixed Capsule) installed on the G1/G2/G3 to reduce installation time and avoid welding on board.
Using existing wiring infrastructure:	Reduce engineering time and vessel disruption, such as ceiling access; by using existing VDR cabling with new retrofit components.
Utilize existing core module rack space and fixing:	The Upgrade Kit helps avoid the need to re-allocate additional space, by incorporating the NW6000’s new components into the existing VDR rack space. Attachments can be fixed to existing bolt holes using our range of retrofit plates, removing the time and hazard implications of drilling or welding new fittings. This is particularly relevant for vessels with flammable cargo, such as LPG carriers.

For more information see Retrofit product datasheet
