Kannad Marine SafePro AIS EPIRB
Kannad Marine SafePro AIS EPIRB

Kannad Marine SAFEPRO + AIS EPIRB

The new SAFEPRO+ AIS EPIRB includes an AIS locating signal and an Infra-Red (Night-Vision) optical signal to aid detection of survivors in low light conditions.

Rugged, multi GNSS 406MHz Satellite EPIRB with both GPS and Galileo receivers, unique inbuilt AIS, optimised for new MEOSAR system


Operating Frequencies:

  • 406MHz
  • 121.5MHz
  • Multi GNSS
  • AIS

Features

  • Built in AIS for localized rescue
  • Multi GNSS including Galileo & GPS
  • Meets the IMO requirement; MSC.471 (101)
  • Infrared (Night-Vision) optical signal
  • Accidental activation protection
  • Rugged construction optimised for commercial environments
  • Hands free carry strap
  • 360-degree strobe
  • Comes with safety bracket
  • 10-year battery life
  • Sealed Electronic Unit
  • Sealed Battery Unit
  • Manual/Auto release options

This device has not been authorized as required by the rules of the Federal Communications Commission. This device is not, and may not be, offered for sale or lease, or sold or leased, until authorization is obtained.

406 MHZ TRANSMITTER

Frequency 406.040 MHz
Power output 5 W nominal
Modulation BSPK (16KOG1D)

121.5 MHZ TRANSMITTER

Frequency 121.5 MHz
Power output 70 mW nominal
Modulation AM Swept tone (3K20A3X)

AIS TRANSMITTER

Frequencies 161.975 MHz (AIS1); 162.025 MHz (AIS2)
Power output 1 W EIRP
Modulation GMSK/FM (16K0GXW)

GNSS RECEIVER

Constellations GPS, Galileo
Frequencies 1575.42 MHz (GPS, Galileo)
Sensitivity -167 dBm minimum
Satellites tracked 92 channels

OPTICAL HOMER

Day and night vision strobe 3 points of high intensity LEDs
Light output 0.75 cd / 2.5 mW/sr minimum
Flash rate 23 flashes per minute

BATTERY

Type Lithium iron disulphide
Operating life 48 hours minimum
Shelf life 10 years from date of manufacture (see Note 1)

ENVIRONMENT

Operating temperature -20 °C to +55 °C (-4 °F to +131 °F)
Storage temperature -30 °C to +70 °C (-22 °F to +158 °F)
Automatic release depth 4 m maximum

DIMENSIONS (EPIRB)

Weight 710 g
Height/Width/Depth 425 X 105 X 105 mm (incl. antenna)
Length of antenna 225 mm

DIMENSIONS (MANUAL BRACKET)

Weight 110 g
Height/Width/Depth 135 x 125 x 125 mm

DIMENSIONS (FLOAT FREE ENCLOSURE)

Weight 1075 g
Height/Width/Depth 415 x 135 x 135 mm

STANDARDS

COSPAS-SARSAT C/S T.001; C/S T.007 – Pending
Europe/UK MED / UKCM – Pending
USA USCG & FCC – Pending
International standards

IEC 61097-2 ED4
IEC 60945 incl. Corrigendum1 (Portable)
IEC 61108-1 (GNSS variant)
RTCM 11000.5
ITU-R M.1371-5
Industry Canada RSS-287
AS/NZS 4280.1

IMO regulations MSC.471(101): A.662(16); A.694(17);
A.814(19)

PART NUMBERS

SAFEPRO+ AIS EPIRB – Manual 23-002-011A
SAFEPRO+ AIS EPIRB – Auto 23-002-511A

NOTE 1: As a responsible manufacturer, Kannad Marine recommends a 5-year health check at the nearest Kannad Marine approved service agent. Shore based maintenance mandated vessels, battery health check or replacements should be carried out in accordance with flag Administration requirements and not exceeding 5 years.
